Panasonic Servo Motor MINAS A6 1500W MHMF152L1G6M
$1.00
Part Number
Series#: MINASA6
Model
Series#: MINASA6
Brand
Others
Material
Others
▌Product Description
Product Details
Series#: Panasonic Servomotor Product Details Panasonic Servo Motor MINAS A6 1500W MHMF152L1G6M We are First Class Panasonic servomotors dealer and Panasonic servomotors distributor in China. We can Supply Panasonic electric automation parts,such as Panasonic PLC,Panasonic Servo Motor&Panasonic servo drive,Panasonic VFD,Panasonic Relay and Panasonic Sensor. 100% Original and new,In stock by Panasonic Electric Delivery time: Ready in stock and 1 days for ship out MOQ: 1pcs
Specification
| Panasonic Servo Motor MINAS A6 | AC200 V |
| Panasonic Servo Motor MINAS A6 IP67 | MHMF152L1□□ |
| Multifunction type | MDDLT55SF |
| RS485 communication type *2 | MDDLN55SG |
| Basic type *2 | MDDLN55SE |
| Frame symbol | D-frame |
| Power supply capacity(kVA) | 2.9 |
| Rated output(W) | 1500 |
| Rated torque(N•m) | 7.16 |
| Continuous stall torque(N•m) | 7.52 |
| Momentary Max. peak torque(N•m) | 21.5 |
| Rated current(A(rms)) | 8 |
| Max. current(A(o-p)) | 34 |
| Regenerative brake frequency (times/min) Note)1Without option | No limit Note)2 |
| DV0P4284 | No limit Note)2 |
| Rated rotational speed(r/min) | 2000 |
| Max. rotational speed(r/min) | 3000 |
| Moment of inertia of rotor (×10−4 kg•m2) | 33.4 |
| Without brake | |
| With brake | 34.6 |
| Recommended moment of inertia ratio of the load and the rotor | 5 times or less |
| Rotary encoder specifications *3 | 23-bit Absolute |
| Resolution per single turn | 8388608 |
